BlindRL#

class deepinv.optim.BlindRL(x_prior=None, k_prior=None, lambda_reg_x=0.0, lambda_reg_k=0.0, g_param=None, g_param_kernel=None, x_steps=1, k_steps=1, kernel_size=(17, 17), normalize_kernel=True, use_fft=False, eps=1e-15, max_iter=100, crit_conv='residual', thres_conv=1e-5, early_stop=False, custom_metrics=None, init=None, cost_fn=None, params_algo=None, unfold=False, DEQ=None, anderson_acceleration=False, **kwargs)[source]#

Bases: BaseOptim

Blind Richardson-Lucy deconvolution for Poisson inverse problems.

This algorithm alternates multiplicative MLEM updates for the image \(x\) and the blur kernel \(h\) under the model

\[y \sim \operatorname{Poisson}(h * x).\]

The updates are given by:

\[h^{(k+1)} = \Pi_{\Delta}\left[\frac{h^{(k)}}{(x^{(k)})^\dagger * \mathbf{1}} \odot (x^{(k)})^\dagger * \left(\frac{y}{x^{(k)} * h^{(k)}}\right)\right],\]

and:

\[x^{(k+1)} = \frac{x^{(k)}}{(h^{(k+1)})^\dagger * \mathbf{1}} \odot (h^{(k+1)})^\dagger * \left(\frac{y}{h^{(k+1)} * x^{(k)}}\right).\]

where \(z^\dagger\) denotes the spatially flipped \(z\), such that \(z^\dagger *\) is the adjoint of convolution by \(z\). The kernel is constrained to be nonnegative and, by default, normalized to unit sum by the Pi_{Delta} operation after each kernel update.

Image and kernel priors can be used. The regularized algorithm is implemented using the the One-Step-Late (OSL) heuristic of Green [1]. The kernel and image updates then become:

\[h^{(k+1)} = \Pi_{\Delta}\left[\frac{h^{(k)}}{(x^{(k)})^\dagger * \mathbf{1} + \lambda_h \nabla R_h(h^{(k)})} \odot (x^{(k)})^\dagger * \left(\frac{y}{x^{(k)} * h^{(k)}}\right)\right].\]
\[x^{(k+1)} = \frac{x^{(k)}}{(h^{(k+1)})^\dagger * \mathbf{1} + \lambda_x \nabla R_x(x^{(k)})} \odot (h^{(k+1)})^\dagger * \left(\frac{y}{h^{(k+1)} * x^{(k)}}\right),\]

Note

The parameter use_fft enables to swap standard convolutions used to update the image and the kernel for FFT based convolutions, which significantly speeds up the algorithm when using a large image and estimating a large kernel. The speedup is particularly important for kernels bigger than 30x30. For small kernels (<15x15) and images (<128x128), it is more efficient to use standard convolutions.

Parameters:

  • x_prior (deepinv.optim.Prior) – optional image prior. Default: None.

  • k_prior (deepinv.optim.Prior) – optional kernel prior. Default: None.

  • lambda_reg_x (float) – image regularization parameter. Default: 0.0.

  • lambda_reg_k (float) – kernel regularization parameter. Default: 0.0.

  • g_param (float) – parameter for the image prior. Default: None.

  • g_param_kernel (float) – parameter for the kernel prior. Default: None.

  • x_steps (int) – number of inner image updates per iteration. Default: 1.

  • k_steps (int) – number of inner kernel updates per iteration. Default: 1.

  • kernel_size (int, tuple[int, int]) – spatial size of the default uniform kernel. An explicit kernel in init overrides this size. Default: (17, 17).

  • normalize_kernel (bool) – whether to normalize the kernel to unit sum. Default: True.

  • use_fft (bool) – whether to use FFT implementations for image and kernel convolutions. Default: False.

  • eps (float) – numerical stability constant. Default: 1e-15.

  • max_iter (int) – number of alternating BlindRL iterations. Default: 100.

  • init (tuple[torch.Tensor, torch.Tensor]) – initial image and blur kernel (x0, k0). If None, x0 is initialized with y and k0 with a uniform kernel of the same size as kernel_size.

  • cost_fn (Callable) – optional cost function. If omitted, the Poisson negative log-likelihood plus explicit image and kernel priors is used.

  • params_algo (dict) – optionally provide BlindRL parameters directly.

References:

forward(y, x_gt=None, compute_metrics=False, **kwargs)[source]#

Run Blind Richardson-Lucy deconvolution.

Parameters:

  • y (torch.Tensor) – blurred image of shape (B, C, H, W).

  • x_gt (torch.Tensor) – optional ground-truth image used to compute metrics. Default: None.

  • compute_metrics (bool) – whether to compute reconstruction metrics. Default: False.

Returns:

estimated image and blur kernel (x, k). If compute_metrics is True, return ((x, k), metrics).

Examples using BlindRL:#

Blind Richardson-Lucy deconvolution

Blind Richardson-Lucy deconvolution
